DESCRIPTION

Basic Info.

Model NO.	VF45.300
Material	Ductile Iron
Type	2-Way
Transport Package	Wooden Case
Specification	DN15-DN400
Trademark	SDCHENXUAN
Origin	Jinan
HS Code	8481100090
Production Capacity	50000

Product Description

VF45 Mixed valve series High closing force flange type two way regulating valve

Product features :

1. Precision casting (resin sand) nodular cast iron GGG-50
2. The valve body adopts the pressure balance type, which guarantees the high clearance ability under the low pressure, and the switching free ability under the high pressure difference
3. Maximum allowable differential pressure is 1000kpa
4. The stem seal uses special sealing process
5. The full metal joint seat increases the value of the life of the valve
6. The product meets GB/T17213-2015 flange connection standard
7. the body uses iron coated sand casting process compared with the traditional technology, there is no swelling phenomenon, body wall thickness, no pores, trachoma material of high density, more exquisite appearance The valve body and stainless steel valve port in the casting process once molding, the valve port will not have deformation phenomenon, long time high temperature use will not exist outside the valve leakage phenomenon, to ensure that the valve port factory pressure test 0 leakage. The sealing ring is made of PTFE+ carbon fiber material, which has better wear resistance The paint paint line and drying equipment make the paint adhesion stronger, the anti-corrosion effect is better, the valve body gloss has been significantly improved.

application:
Suitable for Continuous Control in Regional Heating System and HVAC System.
It can be installed with Siemens SAX, SKD, SKB, SKC series executor.
Order description:

Order model	DN	kv (m3/h)	Trip	SAX 800N	SKD 1000N	SKB 2800N	SKC 2800N
VF45.15	DN15	4	20mm	√	√	○	○
VF45.20	DN20	8		√	√	○	○
VF45.25	DN25	10		√	√	○	○
VF45.32	DN32	12		√	√	○	○
VF45.40	DN40	19		√	√	○	○
VF45.50	DN50	31		√	√	√	○
VF45.65	DN65	49		√	√	√	○
VF45.80	DN80	78		√	√	√	○
VF45.100	DN100	124		○	√	√	○
VF45. 100	DN100	150	40mm	○	○	○	√
VF45. 125	DN125	200		○	○	○	√
VF45.150	DN150	300		○	○	○	√
VF45.200	DN200	420		○	○	○	√
VF45.250	DN250	580		○	○	○	√

√ Represents an optional actuator,○ Represents an optional actuator
