DESCRIPTION

Basic Info.

Model NO.	WY-BW-200
Protection Levels	IP54
Raw Water	Salty Water, Bore Hole Well Water, Bay Water etc
Voltage	110V~450V/50Hz, 60Hz Optional
Inlet Temperature	5-40 Degree
Operation Pressure	1-2.5 MPa
Power	18.27 Kw
Warranty	2 Years
Transport Package	Usually Are Bubble Bag and Wooden Box with Pallet.
Specification	Size(mm)L*W*H: 6000*1600*2200
Trademark	WANGYANG
Origin	China
HS Code	8421219990
Production Capacity	500 Sets Per Month

Product Description

1. System Introduction
1.1 Introduction
Brackish water desalination equipment is applied to high saltness area and Seawater intrusion region, it adopts the most advanced reverse osmosis membrane that from USA, domestic high quality pressure vessel, and imported high pressure pump from Germany, and reasonable pretreatment device. This equipment can remove mineral salt, heavy metal ion, organic bacteria, germ and so on effectively and turn sea water into water that meet standards for drinking water quality.
Features1) Adopting high-quality components and reasonable pre-treatment method.2) Effectively remove harmful ingredients like heavy metal ion,bacterial,etc.3) Applied to high-saltness area and seawater intrusion region.
1.2 Basic Parameter

Raw water
TDS	≤10000mg/L
Inlet Temperature	0~45ºC
Inlet Flow	15.4 m3/h

Product water
TDS	≤700mg/L
Salt Rejection rate	≥99.4%
Product Recovery rate	65%
Product Flow	10 m3/h
Operating Pressure	0.5-2.5Mpa

Power
Voltage	380V/50Hz/three-phase(Optional)
Power	18.27KW
Protection Levels	IP54

Work environment
Environment Temperature	0~45ºC
Air Humidity	20~90%

1.3 Product Specification

200 T/D BRACKISH WATER DESALINATION EQUIPMENT
Model	WY-BW-200
Water Yield	200T/D
Configurations	USA DOW RO membrane / CNP pump(Optional)
Application	Industrial process water treatment
Net Weight	1200KG
Dimension(L*W*H)	6000mm*1600mm*2200mm

1.4 Products Images
2. Process Flow Diagram

Feed pump: equipped with a stainless steel pump, to provide sufficient pressure for subsequent filtration Multimedia filter(Quartz sand filter): mainly remove the mud, suspended solids and large particals in the tap water Activated carbon filter: usually rated by the size of the particles they are able to remove, measured in microns, and generally range from 50 microns (least effective) down to 0.5 microns (most effective). Precision filter: further filtration, protection of reverse osmosis membrane High pressure pump: provide enough pressure for reverse osmosis system Reverse osmosis unit: the core part of pure water equipment, the production of high-purify water Rinse tank: protect the membrane system without polluted by using chemical agent Active Carbon filter: mainly remove organic substance , residual chlorine and odor in tap water
3. About Us
3.1 Company Info
Founded in 2010, Zhuhai Wangyang Water Treatment Equipment Co,.Ltd. is a high-tech enterprise integrated with R&D, production, selling and engineering installation. Specializing in seawater desalination, brackish water desalination, reclaimed-water recycling, hyper pure water, boiler-feeding water, electroplating metallurgy, we have professional technical team and after-sales team. With continuous innovation and good quality guarantee, we have abtained some certificate like ISO9001, CCS, etc. As well, we have our own patent. We persist in the principle "Customers come first, High-quality service, Excellent product". Integrity is the root of our long-term development while customers' satisfaction is our persistent pursuit.

3.2 Company Qualification&Certification

3.3 Packaging&ShippingPackaging: International standard export package.Shipping: 15 working days after receiving 30% deposit of total amount of contract or irrevocable L/C at sight.
4. Payment Terms
40% of the money paid in advance by bank wire transfer after the contract has been confirmed.The rest 60% of the money should be paid by bank wire transfer before the equipment delivery.
5. Equipment Delivery and Installation
Equipment will be delivered or transported within 30 days after advance payment at Zhuhai. Transport mode is freight. The seller has the obligation to install the devices after the devices arriving buyer location. After installation, buyers and sellers organize technicians check out the quantity, quality and function of the devices.During the period of installation, buyer is responsible for locating the devices,basic installation and connection between membrane system devices and other peripheral equipment pipes.
6. Quality Insurance and Service
Total quality assurance to mechanical parts of equipment within 2 years after they transport except normal wear of consumables and easily damaged parts.Our company will provide comprehensive technical support and maintenance services to membrane devices customers use beyond warranty period.
7. Choose Our Technical Advantages
7.1 Choose Our Technical Advantages
* The company has obtained ISO9001 quality management system certificate, Inspection certificate of China classification Society(CCS) and the letter of paten for seawater desalination equipment in container.* We are the direct manufacturer. We have our own factory so that we can offer you high quality product with a good price. * Owning a self brand "WANGYANG" and a professional practical engineer team. * Total water solution is available.* The punctual delivery of goods, quality and quantity guaranteed.* 8 years experinece, OEM&ODM available.7.2 Reverse Osmosis TechnologyReverse osmosis technology is a moderm high technology that use reverse osmosis to seperate water from solution after it permeates the specially-made semi-transparent membrane though exerting a pressure that is higher than the osmosis pressure on the solution. Reserve osmosis / RO water treatment equipment is mainly used in electronic industry, semiconductor industry water treatment, chemical industry, pharmaceutical industry pure water treatment and so on.RO system is widely used in school, hotel, hospital, laboratory and many other public area.
8. FAQ
Q1. Are you a factory or trading company?Yes, we are a manufacturer with designing, manufacturing, marketing and exporting.A. We have sophisticated experience and professional knowledge & technology.B. Both OEM and ODM orders are available. Q2. Where is your factory located? How can I visit there? Our factory is located in No.8, Keji Road 1, Tangjiawan, Xiangzhou district, Zhuhai City, Guangdong, China. All our clients, from home or abroad, are warmly welcome to visit us! We are expecting to establish long-term business relations with you and your company. Q3. What kinds of water treatment equipment do your company offer?We are specialized in designing and manufacturing the products as follow:A.Seawater Desalination G.Reclaimed - Water RecyclingB.Brackish Water Desalination H. Ion- Exchange PlantC. Pure Water Device I. Water Softening PlantD.Medical Hyper Pure Water J. Sewage Treatment PlantF. Ultra Filtration Device K. Zero-Discharged Water Treatment Plant Q4. How are your packing of products?Usually are bubble bag and wooden box with pallet. But we can pack according to customers' requirement.Q5. How should I choose the equipment?It depends on your raw water quality, requirements for permeate water and the water yield.
